| Power | |
|---|---|
| Output power | 1600 W |
| Input operation voltage (min) | 110 V |
| Input operation voltage (max) | 120 V |
| Power supply input frequency | 50/60 |
| Surge energy rating | 570 J |
| Maximum current | 30 A |
| Output power capacity | 2200 VA |
| Ports & interfaces | |
| AC outlets quantity | 7 AC outlet(s) |
| AC outlet types | NEMA 5–15R,NEMA 5–20R,NEMA L5-20R |
| Power plug | NEMA 5-20P |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 1 |
| Modem (RJ-11) ports | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Cable length | 118.1" (3 m) |
| Technical details | |
| Waveform | Sine |
| Form factor | Rackmount/Tower |
| Material | Steel |
| Battery | |
| Number of batteries supported | 1 |
| Typical backup time at half load | 14 min |
| Typical backup time at full load | 4.5 min |
| Hot-swap battery | Yes |
| Cold start | Yes |
| Colour | |
| Colour of product | Black |
| Cooling | |
| Fan | Yes |
| Cooling type | Active |
| Indication | |
| LED indicators | Yes |
| Audible alarm(s) | Yes |
| Design | |
| Rack capacity | 2U |
| Form factor | Rackmount/Tower |
| Colour of product | Black |
| Material | Steel |
| Performance | |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| LED indicators | Yes |
| Cooling type | Active |
| Audible alarm(s) | Yes |
| Packaging data | |
| Package weight | 57.3 lbs (26 kg) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Certificates | |
| Certification | Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A (EMI) |
| RoHS compliance | Yes |
| Weight & dimensions | |
| Package width | 20.2" (514 mm) |
| Package depth | 24" (610 mm) |
| Package height | 9.76" (248 mm) |
| Weight | 47.4 lbs (21.5 kg) |
| Width | 17.5" (444 mm) |
| Package weight | 57.3 lbs (26 kg) |
| Height | 3.5" (89 mm) |
| Depth | 19" (483 mm) |
| Other features | |
| Fan | Yes |
