| Management features | |
|---|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| MIB support | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Fiber ports quantity | 2 |
| Networking | |
| Private VLAN | Yes |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Full duplex | Yes |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| IGMP snooping | Yes |
| Broadcast storm control | Yes |
| 10G support | No |
| Data transmission | |
| Jumbo frames | 10000 |
| Throughput | 14.9 Mpps |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Number of VLANs | 256 |
| Jumbo frames support | Yes |
| Optical fiber | |
| Fiber optic connector | SFP |
| Security | |
| Security algorithms | 802.1x RADIUS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Protocols | |
| Management protocols | HTTP/HTTPS (SSL v2/3 TLS), SNMP v1, v2c, v3, RMON v1, IPv6 |
| Design | |
| Form factor | 1U |
| Colour of product | Black |
| LED indicators | Yes |
| Certification | CE |
| Rack mounting | Yes |
| Performance | |
| Buffer size | 512 KB |
| Mean time between failures (MTBF) | 862966 h |
| Power | |
| Power consumption (max) | 82 W |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Technical details | |
| Form factor | 1U |
| Colour of product | Black |
| Mean time between failures (MTBF) | 862966 h |
| Rack mounting | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 75 W |
| Power over Ethernet (PoE) | Yes |
| Certificates | |
| Certification | CE |
| Indication | |
| LED indicators | Yes |
| System requirements | |
| Compatible operating systems | Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 11" (280 mm) |
| Depth | 4.95" (125.8 mm) |
| Height | 1.73" (44 mm) |
| Weight | 32.5 oz (920 g) |
| Packaging data | |
| AC adapter included | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
| Quick start guide | Yes |
| Cables included | AC |
| Packaging content | |
| AC adapter included | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
| Quick start guide | Yes |
| Cables included | AC |
TRENDnet
