| Power |
|---|
| Output power | 2700 W |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 127 V |
| Output operation voltage (min) | 100 V |
| Output operation voltage (max) | 127 V |
| Power supply input frequency | 50/60 |
| Surge energy rating | 570 J |
| Maximum current | 24 A |
| Efficiency | 94% |
| Emergency Power Off (EPO) | Yes |
| Power factor | 0.9 |
| Crest factor | 3:1 |
| Output power capacity | 3000 VA |
| Ports & interfaces |
|---|
| AC outlets quantity | 9 AC outlet(s) |
| AC outlet types | NEMA 5–15R,NEMA 5–20R,NEMA L5-30R |
| Power plug | NEMA L5-30P |
| Cable length | 118.1" (3 m) |
| Technical details |
|---|
| Form factor | Rackmount/Tower |
| EMI/RFI noise filtering | Yes |
| Surge protection features | Network |
| Material | Steel |
| Battery |
|---|
| Typical backup time at half load | 11 min |
| Typical backup time at full load | 4 min |
| Replacement battery cartridge | RBC96-3U |
| Hot-swap battery | Yes |
| Cold start | Yes |
| Colour |
|---|
| Colour of product | Black |
| Cooling |
|---|
| Cooling type | Active |
| Indication |
|---|
| LED indicators | Yes |
| Audible alarm(s) | Yes |
| Design |
|---|
| Rack capacity | 3U |
| Form factor | Rackmount/Tower |
| Colour of product | Black |
| Material | Steel |
| Display | LCD |
| Performance |
|---|
| UPS topology | Double-conversion (Online) |
| LED indicators | Yes |
| EMI/RFI noise filtering | Yes |
| Surge protection features | Network |
| Noise level | 50 dB |
| Cooling type | Active |
| Audible alarm(s) | Yes |
| Display |
|---|
| Display | LCD |
| Sound emission |
|---|
| Noise level | 50 dB |
| Packaging data |
|---|
| Package weight | 119.9 lbs (54.4 kg) |
| Management features |
|---|
| Management platform | SNMP/Web |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Certificates |
|---|
| Certification | UL1778, CSA, FCC |
| RoHS compliance | Yes |
| Weight & dimensions |
|---|
| Package width | 23" (584 mm) |
| Package depth | 33" (838 mm) |
| Package height | 12" (305 mm) |
| Weight | 74.1 lbs (33.6 kg) |
| Width | 17.5" (444 mm) |
| Package weight | 119.9 lbs (54.4 kg) |
| Height | 5.2" (132 mm) |
| Depth | 26" (660 mm) |
| Other features |
|---|
| Interface | USB, DB9 |
| Output connections | 4 x 5-15R, 4 x 5-15/20R, 1 x L5-30R |
| Relative humidity | 0 - 95% |
| Management platform | SNMP/Web |
