| Power | |
|---|---|
| Output voltage regulation | -21 - 8 |
| Output frequency regulation | 60 |
| Output power | 800 W |
| Input operation voltage (max) | 120 V |
| Output operation voltage (max) | 120 V |
| Surge energy rating | 570 J |
| Maximum current | 15 A |
| Output power capacity | 1000 VA |
| Ports & interfaces | |
| AC outlets quantity | 6 AC outlet(s) |
| AC outlet types | NEMA 5–15R |
| Power plug | NEMA 5-15P |
| USB 2.0 ports quantity | 2 |
| Serial ports quantity | 1 |
| Modem (RJ-11) ports | 1 |
| Cable length | 118.1" (3 m) |
| Technical details | |
| Form factor | Rackmount |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Battery | |
| Battery voltage | 24 V |
| Battery recharge time | 4 h |
| Typical backup time at half load | 15 min |
| Typical backup time at full load | 5.3 min |
| Hot-swap battery | Yes |
| Colour | |
| Colour of product | Black |
| Operational conditions | |
| Non-operating relative humidity (non-condensing) | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Indication | |
| Audible alarm(s) | Yes |
| Design | |
| Rack capacity | 2U |
| Form factor | Rackmount |
| Colour of product | Black |
| Display | LCD |
| Performance | |
| UPS topology | Line-Interactive |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Audible alarm(s) | Yes |
| Display | |
| Display | LCD |
| Packaging data | |
| Package weight | 46.5 lbs (21.1 kg) |
| Certificates | |
| Certification | UL1778, CSA, NOM, FCC |
| Weight & dimensions | |
| Package width | 24" (610 mm) |
| Package depth | 20.2" (514 mm) |
| Package height | 9.02" (229 mm) |
| Weight | 35.5 lbs (16.1 kg) |
| Width | 17.5" (444 mm) |
| Package weight | 46.5 lbs (21.1 kg) |
| Height | 3.5" (89 mm) |
| Depth | 12.5" (317.5 mm) |
| Other features | |
| Non-operating relative humidity (non-condensing) | 0 - 95% |
