| Management features | |
|---|---|
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2+ |
| Ports & interfaces | |
| SFP module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX |
| Networking | |
| Tagged VLAN | Yes |
| Protocol-based VLAN | Yes |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| IGMP snooping | Yes |
| Flow control support | Yes |
| DHCP client | Yes |
| Auto MDI/MDI-X | Yes |
| MAC-based VLAN | Yes |
| Data transmission | |
| Jumbo frames | 9000 |
| Throughput | 26.8 Mpps |
| MAC address table | 8000 entries |
| Switching capacity | 36 Gbit/s |
| Number of VLANs | 4000 |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE-X |
| Security | |
| IP-MAC-Port binding | Yes |
| BPDU filtering/protection | Yes |
| Security algorithms | 802.1x RADIUS,HTTPS,SNMP,SSH,SSH-2,SSL/TLS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Root protection | Yes |
| Queue scheduling algorithms | SP, WRR+SP |
| DHCP snooping | Yes |
| DHCP relay | Yes |
| Design | |
| Colour of product | Black |
| Certification | CE, FCC, RoHS |
| Rack mounting | Yes |
| Performance | |
| Firmware upgradeable | Yes |
| Auto-negotiation | Yes |
| Power | |
| AC input voltage | 100-240 |
| AC input frequency | 50/60 |
| Power consumption (typical) | 12.3 W |
| Technical details | |
| Colour of product | Black |
| Firmware upgradeable | Yes |
| Rack mounting | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Certificates | |
| Certification | CE, FCC, RoHS |
| System requirements | |
| Compatible operating systems | Windows 98SE, NT, 2000, XP, Vista, Windows 7/8, MAC OS, NetWare, UNIX, Linux |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 17.3" (440 mm) |
| Depth | 7.09" (180 mm) |
| Height | 1.73" (44 mm) |
| Packaging data | |
| Rubber feet | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
| User guide | Yes |
| Cables included | AC |
| Packaging content | |
| Rubber feet | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
| User guide | Yes |
| Cables included | AC |
