| Management features | |
|---|---|
| Switch type | Managed network switch |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking | |
| Networking standards | IEEE 802.1p,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Full duplex | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| IGMP snooping | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Data transmission | |
| Throughput | 35.7 Mpps |
| MAC address table | 8000 entries |
| Switching capacity | 48 Gbit/s |
| Store-and-forward | Yes |
| Number of VLANs | 32 |
| Number of queues | 4 |
| Jumbo frames support | Yes |
| Security | |
| IGMP snooping | Yes |
| Design | |
| Colour of product | Black |
| LED indicators | Yes |
| Certification | FCC, CE |
| Rack mounting | Yes |
| Performance | |
| Packet buffer memory | 0.5 MB |
| Power | |
| AC input voltage | 100-240 |
| AC input frequency | 50/60 |
| Technical details | |
| Colour of product | Black |
| Rack mounting | Yes |
| Certificates | |
| Certification | FCC, CE |
| Memory | |
| Packet buffer memory | 0.5 MB |
| Indication | |
| LED indicators | Yes |
| System requirements | |
| Compatible operating systems | Windows 98SE, NT, 2000, XP, Vista, Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 11.6" (294 mm) |
| Depth | 7.09" (180 mm) |
| Height | 1.73" (44 mm) |
