Specifications
- Mfr Part Number: GA-H110M-M.2
- CPU: LGA1151
- Supports 7th/ 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
- Chipset: Intel H110 Express
- Memory: 2x DDR4-2400/ 2133 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 32GB
- Slots: 1x PCI-Express 3.0 x16 Slot, 2x PCI-Express 2.0 x1 Slots
- Storage:
- SATA: 4x SATA3 Ports
- M.2: 1x M.2 Port (M key), Support type 2242/ 2260/ 2280 SATA x2 SSD
- Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC
- LAN: Intel Gigabit Ethernet Controller
- Ports: 4x USB 3.1 Gen1 Ports (2 rear, 2 via header), 6x USB 2.0/1.1 Ports (4 rear, 2 via header), 1x PS/2 Mouse Port, 1x PS/2 Keyboad Port, 1x VGA Port, 1x HDMI Port, 1x DVI-D Port, 1x RJ45 LAN Port, Audio I/O Jacks
- Power Connector: 1x 24pin ATX Main Power Connector, 1x 4pin ATX 12V Power Connector
- Form Factor: MicroATX, 22.6 x 17.4 cm
