| Power | |
|---|---|
| Output power | 600 W |
| Input operation voltage (max) | 120 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 120 V |
| Power supply input frequency | 60 |
| Surge energy rating | 450 J |
| Efficiency | 98% |
| Emergency Power Off (EPO) | Yes |
| Power factor | 0.8 |
| Output power capacity | 750 VA |
| Ports & interfaces | |
| Emergency Power Off (EPO) connector | Yes |
| AC outlets quantity | 6 AC outlet(s) |
| AC outlet types | NEMA 5–15R |
| Power plug | NEMA 5-15P |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
| Cable length | 118.1" (3 m) |
| Technical details | |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Number of input phases | 1 |
| Form factor | Rackmount |
| Number of phases | 1 |
| Response time | 5 ms |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Material | Steel |
| Battery | |
| Battery voltage | 24 V |
| Battery recharge time | 4 h |
| Typical backup time at half load | 13.2 min |
| Typical backup time at full load | 4.9 min |
| Replacement battery cartridge | RBC64-1U |
| Hot-swap battery | Yes |
| Cold start | Yes |
| Battery replacement alarms | Audible |
| Automatic battery test | Yes |
| Colour | |
| Colour of product | Black |
| Cooling | |
| Cooling type | Active |
| Indication | |
| LED indicators | Power, Status |
| Audible alarm(s) | Yes |
| Design | |
| Rack capacity | 1U |
| Form factor | Rackmount |
| Colour of product | Black |
| Material | Steel |
| Performance | |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Number of input phases | 1 |
| Number of phases | 1 |
| Response time | 5 ms |
| LED indicators | Power, Status |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Cooling type | Active |
| Audible alarm(s) | Yes |
| Packaging data | |
| Package weight | 34 lbs (15.4 kg) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Certificates | |
| Certification | UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A (EMI) |
| RoHS compliance | Yes |
| Weight & dimensions | |
| Package width | 23.5" (597 mm) |
| Package depth | 22.5" (572 mm) |
| Package height | 6.26" (159 mm) |
| Weight | 30 lbs (13.6 kg) |
| Width | 17.5" (444 mm) |
| Package weight | 34 lbs (15.4 kg) |
| Height | 1.73" (44 mm) |
| Depth | 16.7" (425 mm) |
| Packaging content | |
| Rack mount kit | Yes |
| Manual | Yes |
| Cables included | USB cable |
