TRENDnet 16-Port Industrial Gigabit PoE+ DIN-Rail Switch - TI-PG162

Specifications
Manufacturer: TRENDnet
Manufacturer Part Number: TI-PG162
Manufacturer Website Address: http://www.trendnet.com
Brand Name: TRENDnet
Product Model: TI-PG162
Product Name: 16-Port Industrial Gigabit PoE+ DIN-Rail Switch
Marketing Information:

TRENDnet's Industrial Gigabit PoE+ DIN-Rail Switches provide network connectivity in rugged environments, while saving you on installation costs and setup time using Power over Ethernet technology. The Industrial Gigabit PoE+ DIN-Rail Switches each feature a rugged IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40° - 75° C (-40° - 167° F). Our hardened industrial PoE+ switch models feature copper Gigabit PoE+ ports for high-speed device connections, and SFP slots that support 1000Base-FX modules for long distance fiber networking applications.

Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Industrial Gigabit PoE+ DIN-Rail Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology inside these industrial PoE+ switches, users will only need one set of cables to deliver both data and power. Network PoE devices to this hardened industrial PoE+ switch, such as high-power wireless access points, IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.

PoE+ Power

This hardened industrial PoE+ switch features a 240W PoE+ power budget that supplies Power over Ethernet devices with 30W of PoE+ power per port.

Redundant Power

Multiple power inputs provide redundant power with overload current protection on this industrial PoE+ switch, minimizing network downtime (power supplies sold separately).

Industrial Hardened Design

Equipped with a rugged IP30 rated housing, designed to withstand a high degree of vibration, shock, and operate within a wide temperature range of -40° - 75° C (-40° - 167° F).

PoE+ Power

Industrial PoE+ switches supply Power over Ethernet devices with up to 30W of PoE+ power per port

Gigabit Ports

Copper Gigabit PoE+ ports for high-speed device connections with the industrial unmanaged PoE+ switch, and SFP slots that support 1000Base-FX modules for long distance fiber networking applications

DIN-Rail / Wall Mounts

Rugged industrial PoE+ switch with IP30 rated metal enclosure, including DIN-Rail mount and wall mount hardware

Redundant Power

Multiple power inputs on the industrial PoE+ switches provide redundant power with overload current protection (power supply sold separately, model: TI-S48048)

Alarm Relay

Alarm relay triggered by power failure of primary and/or redundant power

Jumbo Frame

Supports larger packets, or Jumbo Frames (up to 9KB), for increased performance

Wide Temperature Range

A wide operating temperature range of -40° - 75° C (-40° - 167° F) allows for installations in industrial environments with extreme hot or cold conditions

Shock and Vibration Resistant

These hardened industrial PoE+ switches are rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)

Electro Magnetic Compliance

Complies with industrial EMS certifications (IEC 61000-4-2) ESD: Contact: 6kV | Air: 8kV, (IEC 61000-4-4) EFT: Power: 2kV | Signal: 2kV, (61000-4-5) Surge: Power: 2kV | Signal: 2kV

Grounding Point

This industrial PoE+ switch features a grounding point for protection against external electrical surges

Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 16
Modular: Yes
Port/Expansion Slot Details:

• 14 x Gigabit Ethernet PoE+
• 2 x Gigabit Ethernet Expansion Slot

Media & Performance
Media Type Supported:

• Twisted Pair
• Optical Fiber

Ethernet Technology: Gigabit Ethernet
Network Technology:

• 1000Base-T
• 1000Base-FX

I/O Expansions
Number of Total Expansion Slots: 2
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 2
Network & Communication
Layer Supported: 2
Management & Protocols
Manageable: No
Physical Characteristics
Form Factor:

• DIN Rail Mountable
• Wall Mountable

Height: 1.9"
Width: 0.8"
Length: 6.1"
Weight (Approximate): 1.24 lb
Miscellaneous
Country of Origin: Taiwan
