| Management features | |
|---|---|
| Switch type | Unmanaged network switch |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Networking | |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Data transmission | |
| MAC address table | 8000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Store-and-forward | Yes |
| Maximum data transfer rate | 1 Gbit/s |
| Protocols | |
| Supported network protocols | CSMA/CD, TCP/IP |
| Design | |
| Certification | FCC, CE, RoHS |
| Weight & dimensions | |
| Dimensions (W x D x H) (imperial) | 9.8 x 6.2 x 1.7" |
| Power | |
| Input voltage | 100 - 240 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Certificates | |
| Certification | FCC, CE, RoHS |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 32 - 104 °F |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Other features | |
| Dimensions (WxDxH) | 11.6 x 7.09 x 1.73" (294 x 180 x 44 mm) |
| Connectivity technology | Wired |
| Bandwidth | 16 Gbit/s |
| Networking features | Gigabit Ethernet |
| Input voltage | 100 - 240 |
| Input frequency | 50 - 60 |
| Connectivity LEDs | Yes |
| Dimensions (W x D x H) (imperial) | 9.8 x 6.2 x 1.7" |
