| Management features | |
|---|---|
| ARP inspection | Yes |
| Switch type | Managed network switch |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Installed SFP modules quantity | 4 |
| Networking | |
| Cable types supported | Cat5,Cat5e,Cat6,Cat6a,Cat6e,Cat7 |
| Private VLAN | Yes |
| Networking standards | IEEE 802.11d,IEEE 802.11w,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| VLAN support | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| IP routing | Yes |
| IGMP snooping | Yes |
| Flow control support | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| Data transmission | |
| MAC address table | 16000 entries |
| Switching capacity | 56 Gbit/s |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Security | |
| IP-MAC-Port binding | Yes |
| BPDU filtering/protection | Yes |
| SSH/SSL support | Yes |
| Security algorithms | SSH,SSH-2,SSL/TLS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Design | |
| Colour of product | Black |
| Ventilation fan(s) | 2 |
| Performance | |
| Firmware upgradeable | Yes |
| Technical details | |
| Colour of product | Black |
| Ventilation fan(s) | 2 |
| Firmware upgradeable | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| System requirements | |
| Compatible operating systems | Microsoft Windows XP, Vista, 7, 8, 10, MAC OS, NetWare, UNIX or Linux. |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 17.3" (440 mm) |
| Depth | 1.73" (44 mm) |
| Height | 13" (330 mm) |
| Packaging data | |
| AC adapter included | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
| Quick start guide | Yes |
| Cables included | AC |
| Packaging content | |
| AC adapter included | Yes |
| Rack mount kit | Yes |
| Resource CD | Yes |
| Quick start guide | Yes |
| Cables included | AC |
TP-Link
