| Management features | |
|---|---|
| Switch type | Unmanaged network switch |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking | |
| Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| VLAN support | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| IGMP snooping | Yes |
| Broadcast storm control | Yes |
| Data transmission | |
| Packet forwarding rate (1 Gbps) | 11900000 pps |
| Jumbo frames | 15 |
| MAC address table | 4000 entries |
| Switching capacity | 16 Gbit/s |
| Number of VLANs | 32 |
| Jumbo frames support | Yes |
| Security | |
| Loop protection | Yes |
| IGMP snooping | Yes |
| Design | |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Certification | CE, FCC |
| Performance | |
| Packet buffer memory | 1.5 MB |
| Power | |
| Power consumption (max) | 65.2 W |
| Output voltage | 48 V |
| Output current | 1.25 A |
| AC input voltage | 220 |
| AC input frequency | 50 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) voltage range | 220 - 220 V |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 55 W |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) | Yes |
| Certificates | |
| Certification | CE, FCC |
| Memory | |
| Packet buffer memory | 1.5 MB |
| Indication | |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Weight & dimensions | |
| Width | 6.22" (158 mm) |
| Depth | 3.98" (101 mm) |
| Height | 0.984" (25 mm) |
| Packaging data | |
| User guide | Yes |
| Packaging content | |
| User guide | Yes |
