SpecificationsManufacturer: Supermicro Computer, Inc
Manufacturer Part Number: MBD-X9SCAA-O
Manufacturer Website Address: http://www.supermicro.com
Brand Name: Supermicro
Product Model: X9SCAA
Product Name: X9SCAA Server Motherboard
Marketing Information:
N2800 BOARDS
Supermicro's motherboards based on Intel® Atom™ processor N2800 (Cedarview). These products are well-suited for entry-level server platforms and embedded IPC market.
Product Type: Server Motherboard
Processor & ChipsetChipset Manufacturer: Intel
Processor Socket: Socket BGA-559
Integrated ProcessorIntegrated Processor Manufacturer: Intel
Integrated Processor Type: Atom
Integrated Processor Model: N2800
Integrated Processor Speed: 1.80 GHz
Integrated Processor Core: Dual-core (2 Core)
MemoryNumber of Memory Slots: 2
Memory Form Factor: SoDIMM
Maximum Memory: 4 GB
Memory Speed Supported:
Memory Standard:
- DDR3-1333/PC3-10600
- DDR3-1066/PC3-8500
Memory Technology: DDR3 SDRAM
I/O ControllerController Type: Serial ATA/300
VideoOnboard Video: On-board Video Chipset
Graphics Controller Manufacturer: Intel
Network & CommunicationGigabit Ethernet: Yes
I/O ExpansionsNumber of Total Expansion Slots: 2
Interfaces/PortsTotal Number of USB Ports: 4
Number of USB 2.0 Ports: 2
Number of USB 3.0 Ports: 2
VGA: Yes
HDMI: Yes
DisplayPort: Yes
Number of Network (RJ-45) Ports: 2
Onboard InterfacesNumber of SATA Interfaces: 2
Total Number of Onboard USB Ports: 4
Number of Onboard USB 2.0 Ports: 4
Physical CharacteristicsForm Factor: Mini ITX
Width: 6.7"
Depth: 6.7"
MiscellaneousCompatibility:
1U Chassis:
Mini-ITX Chassis:Environmentally Friendly: Yes
Environmental Certification: RoHS-6
