Supermicro X11SSL-nF Server Motherboard - Intel Chipset - Socket H4 LGA-1151 - MBD-X11SSL-NF-O

Supermicro X11SSL-nF Server Motherboard - Intel Chipset - Socket H4 LGA-1151 - MBD-X11SSL-NF-O

Brand: SuperMicro
Part Number #: MBD-X11SSL-NF-O
UPC: 672000000000
$425.99
$511.19
(You save $85.20 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description
Specifications
Manufacturer: Supermicro Computer, Inc
Manufacturer Part Number: MBD-X11SSL-NF-O
Manufacturer Website Address: http://www.supermicro.com
Brand Name: Supermicro
Product Model: X11SSL-nF
Product Name: X11SSL-nF Server Motherboard
Marketing Information: Xeon® E3-1200 v5 Family Boards / Socket H4 (LGA 1151)

Supermicro's single processor Socket H4 designs feature the Intel® C236/C232 chipset which support the Intel® Xeon E3-1200 v5 processor family and Intel® 6th Gen Core i7/i5/i3 processor family. With outstanding features that include up to 64GB of fast DDR4 DRAM in 4 DIMMS, onboard IPMI or vPro, USB 3.0/USB 3.1, PCI-E 3.0 M.2 and SATA 3.0 (6Gbps) HDD. With support for next generation graphics controller, 4K HD graphics resolution and 3 displays with HDMI, DP, and DVI ports. Designed with performance, reliability, manageability and long life in mind, Supermicro's single processor motherboards are the perfect solution for a variety of server, workstation and embedded applications.


Product Type: Server Motherboard
Processor & Chipset
Chipset Manufacturer: Intel
Total Processor Supported: 1
Processor Socket: Socket H4 LGA-1151
Processor Supported:
  • Core i3
  • Pentium
  • Celeron
  • Xeon

Memory
Number of Memory Slots: 4
Memory Form Factor:
  • DIMM
  • UDIMM

Maximum Memory: 64 GB
Memory Speed Supported:
  • 2.13 GHz
  • 1.87 GHz
  • 1.60 GHz

Memory Technology: DDR4 SDRAM
I/O Controller
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels:
  • 0
  • 1
  • 5
  • 10

Video
Onboard Video: On-board Video Chipset
Graphics Controller Manufacturer: ASPEED
Graphics Controller Model: AST2400
Network & Communication
Gigabit Ethernet: Yes
I/O Expansions
Number of Total Expansion Slots: 3
Total Number of PCI Express Slots: 3
Number of PCI Express x8 Slots: 2
Number of PCI Express x16 Slots: 1
Interfaces/Ports
Total Number of USB Ports: 4
Number of USB 3.0 Ports: 2
VGA: Yes
Onboard Interfaces
Number of SATA Interfaces: 6
Total Number of Onboard USB Ports: 7
Number of Onboard USB 3.0 Ports: 3
Physical Characteristics
Form Factor: Micro ATX
Width: 9.6"
Depth: 9.6"
Miscellaneous
Compatibility: Supermicro SuperChassis

1U Chassis:
  • SC813MFTQC-505CB
  • SC813MFTQ-R400CB
  • SC813MTQ-350CB
  • SC512L-200B
  • SC512F-350B
  • SC811TQ-441B
  • SC113MFAC2-341CB
  • SC113MFAC2-R606CB
  • SC510-203B
  • SC813MFTQC-350CB
2U Chassis:
  • SC213LT-600LPB
  • SC825TQ-R720LPB
  • SC823TQ-653LPB
3U Chassis:
  • SC833T-653B
Mid/Mini Tower Chassis:
  • SC732I-500B
  • SC731i-300B
4U / Tower Chassis:
  • SC842TQ-665B
  • SC842i-500B
