Specifications
- Mfr Part Number: X11SPW-CTF-O
- CPU: Single Socket P LGA3647
- Support Intel Xeon Scalable Processors
- CPU TDP support 205W
- Up to 28 cores
- Chipset: Intel C622
- Memory: 6x 288-pin DDR4-2666/ 2400/ 2133/ 1866/ 1600MHz ECC DIMM Slots, Support up to 768GB 3DS ECC/Load Reduced Memory or up to 384GB ECC/Load Reduced Memory or up to 192GB ECC/REG Memory
- Slots: 1x PCI-Express 3.0 x32 Slot (Left Riser), 1x PCI-Express 3.0 x16 Slot (runs at x8)
- SATA: 10x SATA3 Ports, Support RAID 0, 1, 5, 10
- SAS: 4x SAS3 Ports, SupportRAID 0, 1, 10
- Video: Aspeed AST2500 BMC Graphics
- LAN: Dual LAN with 10GBase-T with Intel X722 + X557
- Ports: 5x USB 3.0 Ports (2 rear, 2 via header, 1 Type A), 7x USB 2.0 Ports (2 rear, 5 via headers), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x 10GbE LAN Ports
- Form Factor: Proprietary WIO, 8.0 x 13.0 inch / 20.32 x 33.02 cm
- RoHS Compliant
