Supermicro X10SRH-CF Server Motherboard - Intel Chipset - Socket LGA 2011-v3 - MBD-X10SRH-CF-O

Supermicro X10SRH-CF Server Motherboard - Intel Chipset - Socket LGA 2011-v3 - MBD-X10SRH-CF-O

Brand: SuperMicro
Part Number #: MBD-X10SRH-CF-O
$714.51
$857.41
(You save $142.90 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description
Specifications
Manufacturer: Supermicro Computer, Inc
Manufacturer Part Number: MBD-X10SRH-CF-O
Manufacturer Website Address: http://www.supermicro.com
Brand Name: Supermicro
Product Model: X10SRH-CF
Product Name: X10SRH-CF Server Motherboard
Marketing Information: Xeon® E5 Family BOARDS / Socket R3 (LGA 2011)

Introducing Supermicro's latest generation of dual processor motherboard technology based on Intel's E5-2600 v3 Haswell processor. Supermicro's X10 motherboards are specifically designed to meet the demanding needs of today's complex computational workloads. Feature rich and highly expandable, our X10 motherboards provide the latest advanced integrated and expandable storage and networking technologies. Features like lightning fast DDR4 memory, NVMe/SAS3/SATA3 storage interfaces, 1G/10GBASE-T, 10G SFP+, 40GbE, and Infiniband QDR/FDR. With its unprecedented set of features, each X10 motherboard is specifically tailored to provide optimal performance while helping to reduce deployment and operational costs over the lifespan of the product.
Product Type: Server Motherboard
Processor & Chipset
Chipset Manufacturer: Intel
Total Processor Supported: 1
Processor Socket: Socket LGA 2011-v3
Processor Supported: Xeon
Memory
Number of Memory Slots: 8
Memory Form Factor:
  • DIMM
  • RDIMM
  • LRDIMM

Maximum Memory: 512 GB
Memory Speed Supported:
  • 2.13 GHz
  • 1.87 GHz
  • 1.60 GHz

Memory Standard:
  • DDR4-1866/PC4-14900
  • DDR4-1600/PC4-12800
  • DDR4-2133/PC4-17000

Memory Technology: DDR4 SDRAM
I/O Controller
Controller Type:
  • Serial ATA/600
  • 12Gb/s SAS

RAID Supported: Yes
RAID Levels:
  • 0
  • 1
  • 10

Video
Onboard Video: On-board Video Chipset
Graphics Controller Manufacturer: ASPEED
Graphics Controller Model: AST2400
Network & Communication
Gigabit Ethernet: Yes
I/O Expansions
Number of Total Expansion Slots: 5
Total Number of PCI Express Slots: 5
Number of PCI Express x1 Slots: 1
Number of PCI Express x8 Slots: 3
Number of PCI Express x16 Slots: 1
Interfaces/Ports
Total Number of USB Ports: 4
Number of USB 2.0 Ports: 2
Number of USB 3.0 Ports: 2
VGA: Yes
Number of Network (RJ-45) Ports: 3
Onboard Interfaces
Number of SATA Interfaces: 10
Number of SAS Interfaces: 8
Total Number of Onboard USB Ports: 8
Number of Onboard USB 2.0 Ports: 6
Number of Onboard USB 3.0 Ports: 2
Physical Characteristics
Form Factor: ATX
Width: 12"
Depth: 9.6"
Miscellaneous
Compatibility: Supermicro SuperChassis

1U Chassis:
  • CSE-813MFTQ-441CB
  • CSE-813MFTQ-R400CB
2U Chassis:
  • CSE-213LT-600LPB
  • CSE-823TQ-653LPB
  • CSE-825TQ-563LPB
  • CSE-825TQ-R600LPB
  • CSE-826TQ-R500LPB
3U Chassis:
  • CSE-833T-653B
  • CSE-836TQ-R500B
Mid-Tower:
  • CSE-732D4F-903B
  • CSE-732i-500B
Tower / 4U Rackmount:
  • CSE-743T-665B
  • CSE-842i-500B
  • CSE-842TQ-665B
  • CSE-842TQ-865B

Environmentally Friendly: Yes
Environmental Certification: RoHS
