Specifications
- Mfr Part Number: SYS-6028TR-HTR
- Motherboard: Super X10DRT-H
- Processor per Node: Dual LGA2011
- Support Intel Xeon E5-2600 v3 Family Processors
- Support up to 18 Cores
- Cache up to 45MB
- QPI up to 9.6 GT/s
- Support up to 145W TDP
- Chipset per Node: Intel C612 Express
- Memory per Node: 8x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, Support up to 512GB ECC/Load Reduced Memory or up to 256GB ECC/REG Memory
- Slots per Node: 3x PCI-Express 3.0 x16 Slots (1 Low-profile, 2 for SMCI Add-on Cards)
- SATA per Node: 3x SATA3 Ports, Support RAID 0, 1, 5
- Video per Node: ASPEED AST2400 BMC Graphics
- LAN per Node: Intel i350-AM2 Dual Port Gigabit Ethernet Controller; 1x Realtek RTL8201N PHY (dedicated IPMI)
- Drive Bays per Node: 3x 3.5" Hot-swap SATA3 Drive Trays
- Ports per Node: 2x USB 3.0 Ports (2 rear, 1 Type A), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
- Form Factor: 2U Rackmount
- Power Supply: 1620W 80 PLUS Platinum Certified High-efficiency Redundant Power Supply w/ PMBus
- System Cooling: 4x 8cm Heavy Duty PWM Fans w/ Optimal Fan Speed Control
- Front Panel:
- Buttons: Power On/Off, System Reset, UID
- LEDs: Power Status, HDD Activity, 2x Network Activity, Universal Information (UID)
- Color: Black
- Dimensions (WxDxH): 17.25 x 28.50 x 3.47 inch / 438.0 x 724.0 x 88.0 mm
- Gross Weight: 85.0 lbs / 38.6 kg
- RoHS Compliant
