Specifications
- Mfr Part Number: SYS-5018A-TN7B
- Motherboard: Super A1SRM-LN7F-2758
- Processor: Intel Atom C2758 Processor, Supports up to 20W TDP (Eight-Core)
- Chipset: System-on-Chip
- Memory: 4x 240pin DDR3-1600/1333 DIMM Slots, Supports up to 64GB ECC or non-ECC Memory
- Slots: 1x PCI-Express 2.0 x8 Slot (runs at x4)
- SATA: 2x SATA3 Ports, 4x SATA2 Ports
- Video: Integrated Aspeed AST2400 BMC Graphics
- LAN: Quad Intel C2000 SoC i354 (2 pairs LAN bypass) & Single Intel i210-AT & Dual Intel i350-AM2 (1 pair LAN bypass) Gigabit Ethernet Controllers
- Drive Bays: 1x 3.5" or 4x 2.5" (opt. bracket required) Internal Drive Bays
- Ports: 7x USB 2.0 Ports (4 rear, 2 via header, 1 Type A), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 7x RJ45 LAN Ports
- Form Factor: 1U Rackmount
- Power Supply: 200W 80 PLUS Gold Certified Low Noise AC-DC Power Supply w/ PFC
- System Cooling: 2x 4cm Counter Rotating PWM Fans, Support up to three System Fans
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: Power, Hard Drive Activity, 2x Network Activity, System Overheat, Information LED (temp, status)
- Color: Black
- Dimensions (WxDxH): 17.2 x 11.3 x 1.7 inch / 437.0 x 287.0 x 43.0 mm
- Weight: 8.45 lbs / 3.83 kg
- RoHS Compliant
