SpecificationsManufacturer: Supermicro Computer, Inc
Manufacturer Part Number: MBD-A2SDI-H-TP4F-O
Manufacturer Website Address: http://www.supermicro.com
Brand Name: Supermicro
Product Model: A2SDI-H-TP4F
Product Name: A2SDI-H-TP4F Server Motherboard
Marketing Information:
C3000 Series BOARDS (System-on-Chip)
Supermicro's motherboards based on Intel® Atom® processor C3000 series System-on-Chip (formerly Denverton) are well-suited for entry-level server platforms and embedded IPC market.
Product Type: Server Motherboard
Processor & ChipsetChipset Manufacturer: Intel
Processor Socket: Socket BGA-1310
Integrated ProcessorIntegrated Processor Manufacturer: Intel
Integrated Processor Type: Atom
Integrated Processor Model: C3958
Integrated Processor Speed: 2 GHz
Integrated Processor Core: Hexadeca-core (16 Core)
MemoryNumber of Memory Slots: 4
Memory Form Factor:
Maximum Memory: 256 GB
Memory Speed Supported:
- 1.87 GHz
- 2.40 GHz
- 2.13 GHz
- 1.60 GHz
Memory Technology: DDR4 SDRAM
I/O ControllerController Type: Serial ATA/600
VideoOnboard Video: On-board Video Chipset
Graphics Controller Manufacturer: ASPEED
Graphics Controller Model: AST2400
Network & Communication10Gigabit Ethernet: Yes
I/O ExpansionsNumber of Total Expansion Slots: 1
Total Number of PCI Express Slots: 1
Number of PCI Express x4 Slots: 1
Interfaces/PortsTotal Number of USB Ports: 2
VGA: Yes
Onboard InterfacesNumber of SATA Interfaces: 4
Number of Mini-SAS Interfaces: 2
Number of M.2 Interfaces: 1
Total Number of Onboard USB Ports: 3
Number of Onboard USB 3.0 Ports: 1
Physical CharacteristicsForm Factor: Mini ITX
Width: 6.7"
Depth: 6.7"
MiscellaneousEnvironmentally Friendly: Yes
Environmental Certification: RoHS
