MSI H170A PC MATE LGA1151/ Intel H170/ DDR4/ 2-Way CrossFireX/ SATA3&USB3.1/ M.2&SATA Express/ A&GbE/ ATX Motherboard

MSI H170A PC MATE LGA1151/ Intel H170/ DDR4/ 2-Way CrossFireX/ SATA3&USB3.1/ M.2&SATA Express/ A&GbE/ ATX Motherboard

Brand: MSI
Part Number #: H170A PC MATE
$294.52
$353.42
(You save $58.90 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Specifications

  • Mfr Part Number: H170A PC MATE
  • CPU: LGA1151
    • Supports 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • Chipset: Intel H170
  • Memory: 4x DDR4-2133 Slots, Dual Channel, ECC, Unbuffered, Max Capacity of 64GB
  • Slots: 2x PCI-Express 3.0 x16 Slots (run at x16 or x16/x4), 3x PCI-Express 3.0 x1 Slots, 2x PCI Slots
  • Multi-Graphics: Supports AMD 2-Way CrossFireX Technology
  • Storage:
    • SATA: 6x SATA3 Ports (2-ports reserved for SATA Express Port), Support RAID 0, 1, 5, 10; 1x SATA Express Ports (PCI-Express 3.0 x2)
    • M.2: 1x M.2 Ports, Support SATA3 & PCI-Express & 4.2/ 6/ 8cm Length M.2 SSD Cards
  • Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC
  • LAN: Realtek RTL8111H Gigabit Ethernet Controller
  • Ports: 8x USB 3.1 Ports (2x Gen2 rear, 4x Gen1 rear, 2x Gen1 via header), 4x USB 2.0 Ports (via headers), 1x PS/2 Mouse Port, 1x PS/2 Keyboard Port, 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x RJ45 LAN Port, Audio I/O Jacks
  • Power Connector: 1x 24pin ATX Main Power Connector, 1x 8pin ATX 12V Power Connector
  • Form Factor: ATX, 12.0 x 8.9 inch / 30.4 x 22.5 cm
