HPE ProLiant DL380 Gen9 High Performance Servers - 803860-B21

HPE ProLiant DL380 Gen9 High Performance Servers - 803860-B21

Brand: HPE
Part Number #: 803860-B21
UPC: 889296123125
$23,029.93
$27,635.92
(You save $4,605.99 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Main Specifications

Product Description HPE ProLiant DL380 Gen9 High Performance - Xeon E5-2690V3 2.6 GHz - 32 GB - 0 GB
Type Server - rack-mountable
Height (Rack Units) 2U
Localization Worldwide (excluding China, Japan)
Server Scalability 2-way
Processor 2 x Intel Xeon E5-2690V3 / 2.6 GHz ( 3.5 GHz ) ( 12-core )
Cache Memory 60 MB L3 cache
Cache Per Processor 30 MB
RAM 32 GB (installed) / 384 GB (max) - DDR4 SDRAM - 2133 MHz - PC4-17000
Storage Controller RAID ( SATA 6Gb/s / SAS 12Gb/s ) - PCIe 3.0 x8 ( Smart Array P440ar with 2GB FBWC )
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage DVD-RW
Graphics Controller Matrox G200eH2
Video Memory 16 MB
Networking GigE, 10 GigE
Power AC 120/230 V
Power Redundancy Yes
Dimensions (WxDxH) 17.5 in x 26.7 in x 3.4 in
Weight 32.54 lbs
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty 3 years warranty - on-site



Extended Specifications

General
Type Server
Product Form Factor Rack-mountable - 2U
Embedded Security Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability 2-way
Hot-Swap Bays Qty 8
Localization Worldwide (excluding China, Japan)
Processor / Chipset
CPU Intel Xeon E5-2690V3 / 2.6 GHz
Max Turbo Speed 3.5 GHz
Number of Cores 12-core
CPU Qty 2
Max CPU Qty 2
CPU Upgradability Upgradable
Cache Memory
Installed Size L3 cache - 60 MB
Cache Per Processor 30 MB
RAM
Installed Size 32 GB / 384 GB (max)
Technology DDR4 SDRAM
Memory Speed 2133 MHz
Memory Specification Compliance PC4-17000
Form Factor DIMM 288-pin
Features Registered, HP SmartMemory
Configuration Features 2 x 16 GB
RAM Supported PC4-17000 - 768 GB - registered ¦ PC4-17000 - 1.5 TB - Load-Reduced
Hard Drive
Type No HDD
Storage Controller
Type 1 x RAID - PCIe 3.0 x8
Controller Interface Type SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name Smart Array P440ar with 2GB FBWC
Channel Qty 8
RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size 2 GB
Optical Storage
Type DVD-RW
Monitor
Monitor Type None.
Graphics Controller
Type Integrated
Graphics Processor Matrox G200eH2
Video Memory 16 MB
Video Interfaces VGA
Networking
Type Integrated
Ethernet Ports 2 x 10 Gigabit Ethernet, 4 x Gigabit Ethernet
Ethernet Controller HP 331i
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 4
Features Wake on LAN (WoL), PXE support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots 2 (total) / 0 (free) x CPU ¦ 24 (total) / 22 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - half-length, full-height ( x8 mode ) ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal) ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height
Interfaces 4 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x HP iLO - RJ-45 ¦ 2 x VGA ( 1 front, 1 rear ) ¦ 5 x USB 3.0 ( 1 front, 2 rear, 2 internal ) ¦ 2 x LAN (10Gigabit Ethernet) ¦ 2 x USB 2.0 ( 2 in front )
Miscellaneous
Included Accessories Cable management arm, HP Easy Install Rails
Features Administrator password, power-on password, serial port I/O control, UEFI BIOS
Compliant Standards ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Power
Device Type Power supply - hot-plug
Power Redundancy Yes
Power Redundancy Scheme 1+1
Installed Qty 2
Max Supported Qty 2
Nominal Voltage AC 120/230 V
Power Provided 800 Watt
80 PLUS Certification 80 PLUS Platinum
Efficiency 94%
Operating System / Software
OS Certified SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer, Canonical Ubuntu
Environmental Standards
ENERGY STAR Qualified Yes
Manufacturer Warranty
Service & Support 3 years warranty
Service & Support Details Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Dimensions & Weight
Width 17.5 in
Depth 26.7 in
Height 3.4 in
Weight 32.54 lbs
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% (non-condensing)
Sound Emission 25 dBA
