HPE ProLiant DL20 Gen9 Servers - 830698-S01

HPE ProLiant DL20 Gen9 Servers - 830698-S01

HPE
SKU:
830698-S01
$1,150.92
$1,381.11
(You save $230.19 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Main Specifications

Product Description HPE ProLiant DL20 Gen9 - Xeon E3-1200 series E3-1240V5 3.5 GHz - 8 GB - 0 GB
Type Server - rack-mountable
Server Scalability 1-way
Processor 1 x Intel Xeon E3-1200 series E3-1240V5 / 3.5 GHz ( Quad-Core )
Cache Memory 8 MB L3 cache
RAM 8 GB (installed) / 64 GB (max) - DDR4 SDRAM - 2133 MHz
Storage Controller RAID ( SATA 6Gb/s ) - PCIe x4 ( HP Dynamic Smart Array B140i )
Server Storage Bays Hot-swap 3.5"
Hard Drive No HDD
Networking GigE
Power AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH) 17.2 in x 15 in x 1.7 in
Manufacturer Selling Program HP Smart Buy
Manufacturer Warranty 1 year warranty



Extended Specifications

General
Type Server
Product Form Factor Rack-mountable
Embedded Security Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability 1-way
Front Accessible Bays Qty 2
Hot-Swap Bays Qty 2
Processor / Chipset
CPU Intel Xeon E3-1200 series E3-1240V5 / 3.5 GHz
Number of Cores Quad-Core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Chipset Type Intel C232
Cache Memory
Installed Size L3 cache - 8 MB
RAM
Installed Size 8 GB / 64 GB (max)
Technology DDR4 SDRAM
Memory Speed 2133 MHz
Form Factor DIMM 288-pin
Features Unbuffered, dual channel memory architecture
Configuration Features 1 x 8 GB
Hard Drive
Type No HDD
Storage Controller
Type 1 x RAID - PCIe x4
Controller Interface Type SATA 6Gb/s
Storage Controller Name HP Dynamic Smart Array B140i
Channel Qty 10
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Monitor
Monitor Type None.
Networking
Interface (Bus) Type PCI Express x2
Ethernet Ports 2 x Gigabit Ethernet
Ethernet Controller HP NC332i
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 4
Features Wake on LAN (WoL), PXE support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays 2 (total) / 2 (free) x external 3.5" LFF
Slots 4 (total) / 3 (free) x DIMM 288-pin ¦ 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card ¦ 1 (total) / 1 (free) x FlexibleLOM
Interfaces 1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 ( 2 in front ) ¦ 3 x USB 3.0 ( 2 rear )
Miscellaneous
Included Accessories HPE Short Friction Rail kit
Manufacturer Selling Program HP Smart Buy
Power
Device Type Power supply
Nominal Voltage AC 120/230 V ( 50/60 Hz )
Power Provided 290 Watt
Operating System / Software
OS Certified SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux
Manufacturer Warranty
Service & Support 1 year warranty
Service & Support Details Limited warranty - 1 year
Dimensions & Weight
Width 17.2 in
Depth 15 in
Height 1.7 in
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90%
