HPE ProLiant DL120 Gen9 Servers - 788090-S01

Name: HPE ProLiant DL120 Gen9 Servers - 788090-S01
Brand: HPE
SKU: 788090-S01
Price: 1330.63 USD
Availability: InStock

HPE

SKU:

788090-S01

$1,330.63

$1,596.75

(You save $266.12 )

(No reviews yet)

Current Stock:

Quantity:

Adding to cart… The item has been added

HPE ProLiant DL120 Gen9 - Server - rack-mountable - 1U - 1-way - 1 x Xeon E5-2609V3 / 1.9 GHz - RAM 8 GB - SATA - hot-swap 3.5" - no HDD - G200eH2 - GigE - Monitor : none - Smart Buy

Main Specifications

Product Description	HPE ProLiant DL120 Gen9 - Xeon E5-2609V3 1.9 GHz - 8 GB - 0 GB
Type	Server - rack-mountable
Height (Rack Units)	1U
Localization	United States
Server Scalability	1-way
Processor	1 x Intel Xeon E5-2609V3 / 1.9 GHz ( 6-core )
Processor Socket	LGA2011-v3 Socket
Cache Memory	15 MB L3 cache
Cache Per Processor	15 MB
RAM	8 GB (installed) / 128 GB (max) - DDR4 SDRAM - Advanced ECC - 1600 MHz - PC4-17000
Storage Controller	RAID ( SATA 6Gb/s ) ( HP Dynamic Smart Array B140i )
Server Storage Bays	Hot-swap 3.5"
Hard Drive	No HDD
Graphics Controller	Matrox G200eH2
Networking	GigE
Power	AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH)	17.1 in x 23.9 in x 1.7 in
Weight	19.84 lbs
Manufacturer Selling Program	HP Smart Buy
Manufacturer Warranty	3 years warranty - on-site ( 1st year only )

Extended Specifications

General

Type	Server
Product Form Factor	Rack-mountable - 1U
Embedded Security	Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability	1-way
Front Accessible Bays Qty	1
Hot-Swap Bays Qty	4
Localization	United States

Processor / Chipset

CPU	Intel Xeon E5-2609V3 / 1.9 GHz
Number of Cores	6-core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Upgradable
CPU Socket	LGA2011-v3 Socket
Chipset Type	Intel C610

Cache Memory

Installed Size	L3 cache - 15 MB
Cache Per Processor	15 MB

RAM

Installed Size	8 GB / 128 GB (max)
Technology	DDR4 SDRAM - Advanced ECC
Memory Speed	1600 MHz
Memory Specification Compliance	PC4-17000
Form Factor	DIMM 288-pin
Features	Registered, Online Spare Memory, HP SmartMemory
RAM Supported	PC4-17000 - 256 GB - Load-Reduced ¦ PC4-17000 - 128 GB - registered

Hard Drive

Type

No HDD

Storage Controller

Type	1 x RAID - integrated
Controller Interface Type	SATA 6Gb/s
Storage Controller Name	HP Dynamic Smart Array B140i
Channel Qty	10
RAID Level	RAID 0, RAID 1, RAID 5, RAID 10

Monitor

Monitor Type

None.

Graphics Controller

Type	Integrated
Graphics Processor	Matrox G200eH2

Networking

Type	Integrated
Interface (Bus) Type	PCI Express 2.0 x2
Ethernet Ports	2 x Gigabit Ethernet
Ethernet Controller	HP NC361i
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller	Integrated Lights-Out 4
Features	Wake on LAN (WoL), ACPI support, PXE support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1as, IEEE 802.3az

Expansion / Connectivity

Bays	1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots	8 DIMM 288-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile ( x16 mode ) ¦ 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces	1 x VGA ¦ 1 x USB 2.0 ( 1 front ) ¦ 3 x USB 3.0 ( 2 rear, 1 internal ) ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HP iLO

Miscellaneous

Included Accessories	HP Easy Install Rail kit
Features	Administrator password, power-on password, serial port I/O control
Compliant Standards	ACPI 2.0b, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, GB 9254, ASHRAE, CNS 13438
Manufacturer Selling Program	HP Smart Buy

Power

Device Type	Power supply
Nominal Voltage	AC 120/230 V ( 50/60 Hz )
Power Provided	550 Watt

Operating System / Software

OS Certified

SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux

Manufacturer Warranty

Service & Support	3 years warranty
Service & Support Details	Limited warranty - parts - 3 years - response time: next business day ¦ Limited warranty - parts and labor - 1 year - on-site - response time: next business day

Dimensions & Weight

Width	17.1 in
Depth	23.9 in
Height	1.7 in
Weight	19.84 lbs

Environmental Parameters

Min Operating Temperature	50 °F
Max Operating Temperature	95 °F
Humidity Range Operating	8 - 90%
