HPE 3100-24 v2 SI Switch - switch - 24 ports - managed - rack-mountable

Brand: HPE
Part Number #: JG223A
$548.09
$657.71
(You save $109.62 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Main Specifications

Product Description HPE 3100-24 v2 SI Switch - switch - 24 ports - managed - rack-mountable
Device Type Switch - 24 ports - L3 - managed - stackable
Enclosure Type Rack-mountable 1U
Subtype Fast Ethernet
Ports 24 x 10/100 + 2 x 10/100/1000
Performance Throughput : 6.6 Mpps ¦ Routing/switching capacity : 8.8 Gbps
MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI
Features Flow control, BOOTP support, ARP support, VLAN support, IGMP snooping, Quality of Service (QoS)
Compliant Standards IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP)
Power AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH) 17.3 in x 6.3 in x 1.7 in
Weight 6.61 lbs



Extended Specifications

General
Device Type Switch - 24 ports - L3 - managed - stackable
Enclosure Type Rack-mountable 1U
Subtype Fast Ethernet
Ports 24 x 10/100 + 2 x 10/100/1000
Performance Throughput : 6.6 Mpps ¦ Routing/switching capacity : 8.8 Gbps
MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI
Encryption Algorithm SSL
Authentication Method RADIUS, Secure Shell v.2 (SSH2)
Features Flow control, BOOTP support, ARP support, VLAN support, IGMP snooping, Quality of Service (QoS)
Compliant Standards IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP)
RAM 128 MB - SDRAM
Flash Memory 16 MB
Expansion / Connectivity
Interfaces 24 x 10Base-T/100Base-TX - RJ-45 ¦ 1 x console - RJ-45 ¦ 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x SFP (mini-GBIC)
Power
Power Device Internal power supply
Voltage Required AC 120/230 V ( 50/60 Hz )
Miscellaneous
Rack Mounting Kit Included
Compliant Standards CISPR 22 Class A, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, FCC CFR47 Part 15, EN300-386, UL 60950-1, FCC Part 15 A, EN 60825-1
Dimensions & Weight
Width 17.3 in
Depth 6.3 in
Height 1.7 in
Weight 6.61 lbs
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 113 °F
Humidity Range Operating 10 - 90% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F
Humidity Range Storage 5 - 95% (non-condensing)
