| Design | |
|---|---|
| Product type | Notebook |
| Market positioning | Business |
| Form factor | Clamshell |
| Colour of product | Silver |
| Display | |
| HD type | Full HD |
| Panel type | IPS |
| LED backlight | Yes |
| Aspect ratio | 16:9 |
| Touchscreen | Yes |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 14" |
| Screen shape | Flat |
| Processor | |
| Stepping | Y0 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Kaby Lake R |
| Bus type | OPI |
| Tjunction | 100 °C |
| Thermal Design Power (TDP) | 15 W |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
| Maximum number of PCI Express lanes | 12 |
| ECC supported by processor | No |
| Configurable TDP-down frequency | 800 MHz |
| Processor cache type | Smart Cache |
| Conflict Free processor | Yes |
| Processor cache | 6 MB |
| Processor frequency | 1.70 GHz |
| Processor model | i5-8350U |
| Processor boost frequency | 3.60 GHz |
| Processor cores | 4 |
| Processor threads | 8 |
| System bus rate | 4 GT/s |
| Processor socket | BGA 1356 |
| Processor family | 8th gen Intel® Core™ i5 |
| Memory | |
| Memory form factor | SO-DIMM |
| Internal memory | 8 GB |
| Memory layout (slots x size) | 1 x 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2400 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Storage | |
| Storage media | SSD |
| Number of SSDs installed | 1 |
| Solid-state drive capacity | 256 GB |
| Card reader integrated | Yes |
| Total storage capacity | 256 GB |
| Graphics | |
| Discrete graphics adapter | No |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| On-board graphics adapter base frequency | 300 MHz |
| Maximum on-board graphics adapter memory | 32 GB |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics adapter DirectX version | 12.0 |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter ID | 0x5917 |
| On-board graphics adapter | Yes |
| On-board graphics adapter model | Intel UHD Graphics 620 |
| Discrete graphics adapter model | Not available |
| Audio | |
| Number of built-in speakers | 2 |
| Speakers manufacturer | Bang & Olufsen |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| WLAN controller model | Intel Dual Band Wireless-AC 8265 |
| 4G | No |
| Near Field Communication (NFC) | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| 3G | No |
| Ports & interfaces | |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4b |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Docking connector | Yes |
| DC-in jack | Yes |
| Performance | |
| Ambient light sensor | Yes |
| Keyboard | |
| Pointing device | Clickpad |
| Numeric keypad | No |
| Windows keys | Yes |
| Spill resistant keyboard | Yes |
| Keyboard backlit | Yes |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Technical details | |
| Market positioning | Business |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Smart Response Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Form factor | Clamshell |
| Colour of product | Silver |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Secure Key | Yes |
| Intel Flex Memory Access | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Thermal Monitoring Technologies | Yes |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Processor package size | 42 x 24 |
| Processor code | SR3L9 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 124969 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Smart Response Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Brand-specific features | |
| HP Security tools | HP BIOS Config Utility (BCU); HP Client Catalog; HP Driver Packs; HP System Software Manager (SSM); HP Manageability Integration Kit Gen2 |
| HP Management tools | HP BIOSphere Gen4; HP Device Access Manager; HP DriveLock and Automatic DriveLock; HP Fingerprint Sensor; HP Password Manager; HP Secure Erase; HP Security Manager,HP Sure Click; HP SureStart Gen4; Measured Boot; HP Host Based Mac Address |
| HP speaker type | HP Dual Speakers |
| HP Smart AC Adapter | Yes |
| HP special features | |
| HP Security tools | HP BIOS Config Utility (BCU); HP Client Catalog; HP Driver Packs; HP System Software Manager (SSM); HP Manageability Integration Kit Gen2 |
| HP Management tools | HP BIOSphere Gen4; HP Device Access Manager; HP DriveLock and Automatic DriveLock; HP Fingerprint Sensor; HP Password Manager; HP Secure Erase; HP Security Manager,HP Sure Click; HP SureStart Gen4; Measured Boot; HP Host Based Mac Address |
| HP speaker type | HP Dual Speakers |
| HP Smart AC Adapter | Yes |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
| Battery capacity (Watt hours) | 50 Wh |
| Power | |
| AC adapter power | 65 W |
| Security | |
| Trusted Platform Module (TPM) | Yes |
| Fingerprint reader | Yes |
| Cable lock slot | Yes |
| Certificates | |
| Energy Star certified | Yes |
| EPEAT compliance | Gold |
| Weight & dimensions | |
| Width | 12.8" (326 mm) |
| Depth | 9.21" (234 mm) |
| Height | 0.705" (17.9 mm) |
| Weight | 3.55 lbs (1.61 kg) |
| Packaging data | |
| AC adapter included | Yes |
| Other features | |
| Ambient light sensor | Yes |
| WLAN controller model | Intel Dual Band Wireless-AC 8265 |
| On-board graphics adapter | Yes |
| Sensors | |
| Ambient light sensor | Yes |
| Packaging content | |
| AC adapter included | Yes |
