| Projector | |
|---|---|
| Number of colours | 1.073 billion colors |
| Projector native resolution | WUXGA (1920x1200) |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 30 - 300" |
| Projection distance | 29.9 - 300" (0.76 - 7.62 m) |
| Contrast ratio (typical) | 15000:1 |
| Zoom ratio | 1.6:1 |
| Matrix type | 3-panel (p-Si TFT active) |
| Keystone correction, vertical | -30 - 30 |
| Keystone correction, horizontal | -30 - 30 |
| Projection technology | 3LCD |
| Projector brightness | 3800 ANSI lumens |
| Projection modes | Ceiling, Front, Rear |
| Lamps | |
| Service life of lamp | 6000 h |
| Bulb power | 210 W |
| Lamp type | UHE |
| Service life of lamp (economic mode) | 12000 h |
| Lamps quantity | 1 lamp(s) |
| Lens system | |
| Focus | Manual |
| Focal length range (f-f) | 0.799 - 1.28" (20.3 - 32.5 mm) |
| Aperture range (F-F) | 1.51 - 1.99 |
| Throw ratio | 1.39 - 2.23:1 |
| Video | |
| Video processing | 10 bit |
| Analog signal format system | NTSC,NTSC 4.43,PAL,PAL 60,PAL M,PAL N,SECAM |
| Full HD | Yes |
| 3D | No |
| Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 960, 1366 Ñ… 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900 |
| Audio | |
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
| Ports & interfaces | |
| Mobile High-Definition Link (MHL) | Yes |
| HDMI connector type | Full-size |
| USB 2.0 Type-B ports quantity | 1 |
| PC in (D-Sub) | Yes |
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| Audio (L,R) in | 1 |
| RS-232 ports | 1 |
| PC Audio out | Yes |
| PC Audio in | Yes |
| DVI port | No |
| Component video (YPbPr/YCbCr) in | 1 |
| AC (power) in | Yes |
| Networking | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage | |
| Card reader integrated | No |
| Sound emission | |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Technical details | |
| PC in (D-Sub) | Yes |
| Colour of product | White |
| Plug and Play | Yes |
| RS-232C | Yes |
| Projection modes | Ceiling, Front, Rear |
| Performance | |
| Plug and Play | Yes |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Multimedia | |
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
| Design | |
| Product type | Desktop projector |
| Cable lock slot type | Kensington |
| Colour of product | White |
| Cable lock slot | Yes |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power source | AC |
| Power consumption (typical) | 326 W |
| Power consumption (standby) | 2 W |
| Power consumption (economy mode) | 237 W |
| Security | |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Certificates | |
| RoHS compliance | Yes |
| Weight & dimensions | |
| Weight | 7.05 lbs (3.2 kg) |
| Width | 12.1" (307 mm) |
| Depth | 11.5" (292 mm) |
| Height | 4.09" (104 mm) |
| Packaging content | |
| Handheld remote control | Yes |
| Warranty card | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Cables included | AC, VGA |
| Batteries included | Yes |
| Other features | |
| Power consumption (economy mode) | 237 W |
