| Projector | |
|---|---|
| Number of colours | 1.073 billion colors |
| White light output | 3500 ANSI lumens |
| Colour light output | 3500 ANSI lumens |
| Projector native resolution | WXGA (1280x800) |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 60 - 100" |
| Projection distance | 13.4 - 23.6" (0.34 - 0.6 m) |
| Contrast ratio (dynamic) | 14000:1 |
| Zoom ratio | 1.35:1 |
| Matrix type | 3-panel (p-Si TFT active) |
| Keystone correction, vertical | -3 - 3 |
| Keystone correction, horizontal | -3 - 3 |
| Projection technology | 3LCD |
| Projector brightness | 3500 ANSI lumens |
| Lamps | |
| Service life of lamp | 5000 h |
| Bulb power | 250 W |
| Lamp type | UHE |
| Service life of lamp (economic mode) | 10000 h |
| Lens system | |
| Fixed focal length | 0.146" (3.7 mm) |
| Focus | Manual |
| Throw ratio | 0.28 - 0.37:1 |
| Digital zoom | 1.35x |
| Video | |
| Analog signal format system | NTSC,NTSC 4.43,PAL,PAL 60,PAL M,PAL N,SECAM |
| Full HD | No |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 16 W |
| Ports & interfaces | |
| Mobile High-Definition Link (MHL) | Yes |
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| Audio (L,R) in | 3 |
| Audio (L,R) out | 1 |
| Microphone in | Yes |
| RS-232 ports | 1 |
| DVI port | No |
| Networking | |
| Ethernet LAN | Yes |
| Sound emission | |
| Noise level | 35 dB |
| Noise level (economic mode) | 29 dB |
| Technical details | |
| Colour of product | Grey, White |
| Ceiling mounting supported | Yes |
| RS-232C | Yes |
| Performance | |
| Password protection | Yes |
| Noise level | 35 dB |
| Noise level (economic mode) | 29 dB |
| Multimedia | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 16 W |
| Design | |
| Product type | Wall-mounted projector |
| Cable lock slot type | Kensington |
| Colour of product | Grey, White |
| Ceiling mounting supported | Yes |
| Cable lock slot | Yes |
| Power | |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power source | AC |
| Power consumption (typical) | 373 W |
| Power consumption (standby) | 2.2 W |
| Power consumption (economy mode) | 324 W |
| Security | |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 °C |
| Certificates | |
| RoHS compliance | Yes |
| Weight & dimensions | |
| Weight | 12.6 lbs (5.71 kg) |
| Width | 14.5" (368 mm) |
| Depth | 15.8" (401 mm) |
| Height | 7.4" (188 mm) |
| Packaging content | |
| Handheld remote control | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Batteries included | Yes |
| Other features | |
| Power consumption (economy mode) | 324 W |
