| Design | |
|---|---|
| Intel segment tagging | Enterprise |
| Product type | Notebook |
| Form factor | Clamshell |
| Colour of product | Grey |
| Display | |
| HD type | Full HD |
| Display surface | Gloss |
| LED backlight | Yes |
| Aspect ratio | 16:9 |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 12.5" |
| Processor | |
| Stepping | H0 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Kaby Lake |
| Bus type | OPI |
| Tjunction | 100 °C |
| Thermal Design Power (TDP) | 15 W |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
| Maximum number of PCI Express lanes | 12 |
| ECC supported by processor | No |
| Configurable TDP-down frequency | 800 MHz |
| Processor cache type | Smart Cache |
| Conflict Free processor | Yes |
| Processor cache | 3 MB |
| Processor frequency | 2.50 GHz |
| Processor model | i5-7200U |
| Processor boost frequency | 3.10 GHz |
| Processor cores | 2 |
| Processor threads | 4 |
| System bus rate | 4 GT/s |
| Processor socket | BGA 1356 |
| Processor family | 7th gen Intel® Core™ i5 |
| Memory | |
| Memory form factor | On-board |
| Internal memory | 8 GB |
| Internal memory type | LPDDR3-SDRAM |
| Memory clock speed | 2133 MHz |
| Maximum internal memory | 16 GB |
| Storage | |
| Storage media | SSD |
| Total storage capacity | 256 GB |
| Graphics | |
| Discrete graphics adapter | No |
| On-board graphics adapter dynamic frequency (max) | 1000 MHz |
| On-board graphics adapter base frequency | 300 MHz |
| Maximum on-board graphics adapter memory | 32 GB |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics adapter DirectX version | 12.0 |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter ID | 0x5916 |
| On-board graphics adapter family | Intel® HD Graphics |
| On-board graphics adapter | Yes |
| On-board graphics adapter model | Intel HD Graphics 620 |
| Discrete graphics adapter model | Not available |
| Audio | |
| Audio system | SonicMaster Premium |
| Camera | |
| Front camera | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| 4G | No |
| Wi-Fi | Yes |
| Wi-Fi standards | IEEE 802.11ac |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| 3G | No |
| Ports & interfaces | |
| USB 3.1 (3.1 Gen 2) Type-C ports quantity | 1 |
| DVI port | No |
| Combo headphone/mic port | Yes |
| Docking connector | No |
| Keyboard | |
| Pointing device | Touchpad |
| Numeric keypad | No |
| Windows keys | Yes |
| Software | |
| Operating system installed | Windows 10 Home |
| Technical details | |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel® vPro™ Technology | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Smart Response Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Form factor | Clamshell |
| Colour of product | Grey |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | No |
| Intel Trusted Execution Technology | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Secure Key | Yes |
| Intel Flex Memory Access | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Thermal Monitoring Technologies | Yes |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Processor package size | 42 x 24 |
| Processor code | SR2ZU |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Graphics & IMC lithography | 14 nm |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 95443 |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel® vPro™ Technology | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Smart Response Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Battery | |
| Battery technology | Polymer |
| Number of battery cells | 6 |
| Battery capacity (Watt hours) | 40 Wh |
| Power | |
| AC adapter power | 45 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 2.25 A |
| AC adapter output voltage | 20 V |
| Security | |
| Fingerprint reader | Yes |
| Weight & dimensions | |
| Width | 11.7" (296 mm) |
| Depth | 7.53" (191.2 mm) |
| Height | 0.469" (11.9 mm) |
| Weight | 32.1 oz (910 g) |
| Other features | |
| On-board graphics adapter | Yes |
| Audio system | SonicMaster Premium |
