Asus H170I-PLUS D3 LGA1151/ Intel H170/ DDR3/ SATA3&USB3.0/ M.2&SATA Express/ WiFi/ A&GbE/ Mini-ITX Motherboard

Asus H170I-PLUS D3 LGA1151/ Intel H170/ DDR3/ SATA3&USB3.0/ M.2&SATA Express/ WiFi/ A&GbE/ Mini-ITX Motherboard

Brand: ASUS
Part Number #: H170I-PLUS D3
$294.52
$353.42
(You save $58.90 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Specifications

  • Mfr Part Number: H170I-PLUS D3
  • CPU: LGA1151
    • Supports the 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
    • Supports 14nm CPU
    • Supports Intel Turbo Boost Technology 2.0
  • Chipset: Intel H170
  • Memory: 2x DDR3-1866(OC)/ 1600/ 1333 DIMM Slots, Non-ECC, Unbuffered, Max Capacity of 32GB
  • Slots: 1x PCI-Express 3.0/2.0 x16 Slot
  • Storage:
    • SATA: 4x SATA3 Ports, 1x SATA Express Port (Compatible w/ 2x SATA 6.0 Gb/s ports)
    • M.2: 1x M.2 Port (type 2242/ 2260/ 2280), Support Both SATA & PCI-Express Mode
  • Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC
  • LAN: Intel i219V Gigabit Ethernet Controller, Wi-Fi 802.11a/b/g/n/ac Wireless LAN (2.4/5GHz), Bluetooth v4.0
  • Ports: 8x USB 3.0/2.0 Ports (6 rear, 2 at mid-board), 4x USB 2.0/1.1 Ports (4 at mid-board), 1x PS/2 Keyboard/ Mouse Combo Port, 1x VGA Port, 1x DVI-D Port, 1x DisplayPort, 1x HDMI Port, 1x ASUS Wi-Fi GO! Module, 1x Optical S/PDIF Out, 1x RJ45 LAN Port, Audio I/O Jacks
  • Power Connector: 1x 24pin EATX Power Connector, 1x 4pin ATX 12V Power Connector
  • Form Factor: Mini ITX, 6.7 x 6.7 inch / 17.0 x 17.0 cm
