Specifications
- Mfr Part Number: Z170M-ITX/AC
- CPU: LGA 1151
- Supports 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
- Digi Power Design
- 6 Phase Power Design
- Supports Intel Turbo Boost 2.0 Technology
- Supports Intel K-Series unlocked CPUs
- Supports ASRock BCLK Full-range Overclocking
- Chipset: Intel Z170
- Memory: 2x DDR4-3200+(OC)/ 2933(OC)/ 2800(OC)/ 2400(OC)/ 2133 DIMM Slots, Dual-Channel, Non-ECC, Unbuffered, Max capacity up to 32GB
- Slots: 1x PCI-Express 3.0 x16 Slot; 1x Vertical Half-size Mini-PCI Express Slot (For WiFi + BT Module)
- SATA: 4x SATA3 Ports, Support RAID 0, 1, 5, 10, 1x mSATA Ports
- Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC, Supports Premium Blu-ray Audio
- LAN: Realtek RTL8111H PCI-Express x1 and Intel I219-V Gigabit Ethernet Controller
- Ports: 8x USB 3.0 Ports (6 rear, 2 via header), 4x USB 2.0 Ports (2 rear, 2 via header), 1x PS/2 Keyboard/Mouse Combo Port, 1x DVI-D Port, 1x HDMI Port, 1x DisplayPort, 2x RJ45 LAN Ports, Audio I/O Jacks
- Power Connector: 1x 20pin ATX Power Connector, 1x 4pin 12V Power Connector
- Form Factor: Mini-ITX
