Specifications
- Mfr Part Number: H81TM-ITX R2.0
- CPU: LGA1150
- Supports New 4th/ 4th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron/ Xeon Processors
- Supports up to 65W TDP
- Supports Intel Turbo Boost 2.0 Technology
- Chipset: Intel H81
- Memory: 2x DDR3-1600/ 1333/ 1066 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 16GB
- Slots: 1x PCI-Express 2.0 x4 Slot, 1x Half Mini-PCI Express Slot
- SATA: 2x SATA3 Ports
- Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC
- LAN: Giga PHY Intel I218V Gigabit Ethernet Controller
- Ports: 2x USB 3.0 Ports, 7x USB 2.0 Ports (2 rear, 5 via headers), 1x DVI-I Port, 1x HDMI Port, 1x RJ45 LAN Port, Audio I/O Jacks
- Power Connector: 1x DC Jack Connector
- Form Factor: Thin Mini-ITX
