| Projector | |
|---|---|
| Number of colours | 1.073 billion colors |
| Projector native resolution | 1080p (1920x1080) |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3, 16:9 |
| Screen size compatibility | 54 - 300" |
| Contrast ratio (typical) | 20000:1 |
| Zoom capability | Manual |
| Vertical synchronization (min) | 0.024 kHz |
| Vertical synchronization (max) | 0.12 kHz |
| Keystone correction, vertical | -30 - 30 |
| Keystone correction, horizontal | -30 - 30 |
| Horizontal synchronization (min) | 15 kHz |
| Horizontal synchronization (max) | 100 kHz |
| Projection technology | DLP |
| Projector brightness | 2200 ANSI lumens |
| Lamps | |
| Service life of lamp | 3000 h |
| Bulb power | 240 W |
| Lamp type | UHP |
| Service life of lamp (economic mode) | 4000 h |
| Lamps quantity | 1 lamp(s) |
| Lens system | |
| Focus | Manual |
| Focal length range (f-f) | 0.402 - 0.442" (10.2 - 11.2 mm) |
| Aperture range (F-F) | 2.6 - 2.78 |
| Throw ratio | 0.69 - 0.76:1 |
| Optical zoom | 1.1x |
| Digital zoom | 2x |
| Video | |
| Analog signal format system | NTSC,PAL,SECAM |
| Full HD | Yes |
| 3D | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 3 |
| USB 2.0 ports quantity | 1 |
| USB connector type | Micro-USB B |
| Composite video in | 1 |
| Audio (L,R) in | 1 |
| Audio (L,R) out | 1 |
| S-Video inputs quantity | 1 |
| Component video (YPbPr/YCbCr) in | 1 |
| Sound emission | |
| Noise level | 30 dB |
| Noise level (economic mode) | 33 dB |
| Technical details | |
| Colour of product | Black, Red |
| Ceiling mounting supported | Yes |
| Performance | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Noise level | 30 dB |
| Noise level (economic mode) | 33 dB |
| Multimedia | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
| Design | |
| Product type | Desktop projector |
| Colour of product | Black, Red |
| Ceiling mounting supported | Yes |
| Power | |
| AC input voltage | 120 - 230 |
| Power source | AC |
| Power consumption (typical) | 424 W |
| Power consumption (PowerSave) | 360 W |
| Software | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Weight | 7.5 lbs (3.4 kg) |
| Packaging content | |
| Handheld remote control | Yes |
| User guide | Yes |
| Quick start guide | Yes |
| Carrying case | Yes |
| Cables included | AC, VGA |
| Batteries included | Yes |
